Description
|
Voltage level |
Single phase 220VAC |
Single phase/three phase 220VAC |
|||||||
|
Motor Model |
5G-130ST |
||||||||
|
CS/CM05415B |
CS/CM05415BZ |
TL05415B |
TL05415BZ |
CS/CM06025B |
CS/CM06025BZ |
CS/CM10015B |
CS/CM10015BZ |
||
|
20P8-S01 |
20P8-S01 |
20P8-S01 |
20P8-S01 |
21P5-S01 |
21P5-S01 |
21P5-S01 |
21P5-S01 |
||
|
Motor code |
5072 |
5872 |
9072 |
9872 |
5078 |
5878 |
5079 |
5879 |
|
|
Rated power (KW) |
0.85 |
0.85 |
0.85 |
0.85 |
1.5 |
1.5 |
1.5 |
1.5 |
|
|
Rated current [mA] |
4200 |
4200 |
4200 |
4200 |
7500 |
7500 |
7500 |
7500 |
|
|
Rated speed [RPM] |
1500 |
1500 |
1500 |
1500 |
2500 |
2500 |
1500 |
1500 |
|
|
Maximum speed [RPM] |
2000 |
2000 |
2000 |
2000 |
3000 |
3000 |
2500 |
2500 |
|
|
Rated torque [Nm] |
5.4 |
5.4 |
5.4 |
5.4 |
6 |
6 |
10 |
10 |
|
|
Maximum torque [Nm] |
15.12 |
15.12 |
15.12 |
15.12 |
15 |
15 |
25 |
25 |
|
|
Rotor inertia [10^-7kg.m2] |
8480 |
9717 |
8480 |
9717 |
9440 |
11200 |
14400 |
16261 |
|
|
Inertia Type |
Medium inertia |
Medium inertia |
Medium inertia |
Medium inertia |
Medium inertia |
Medium inertia |
Medium inertia |
Medium inertia |
|
|
Pole pairs |
5 |
5 |
5 |
5 |
5 |
5 |
5 |
5 |
|
|
Encoder Bits |
17 |
17 |
twenty three |
twenty three |
17 |
17 |
17 |
17 |
|
|
Encoder Type |
magnetic |
magnetic |
Light |
Light |
magnetic |
magnetic |
magnetic |
magnetic |
|
|
Motor insulation class |
Class F (155°C) |
||||||||
|
Protection level |
IP65 |
||||||||
|
Usage Environment |
Ambient temperature |
-15℃～+40℃ |
|||||||
|
Ambient humidity |
Relative humidity <90% (no condensation) |
||||||||
