Description
Fast speed, stable performance, meeting diverse needs
In addition to all functions of standard PLC, it has faster processing speed (about 15 times that of XC series), larger internal resource space, two-axis linkage, interpolation and follow-up functions, and supports external SD card for data storage. Support the connection of right expansion module, expansion BD board and left expansion module.
Basic functions and configurations
Program capacity 512KB~1.5MB
Basic instruction 0.02~0.05us
Max I/O 572 points
I/O sequential control
USB port high-speed download (max 12Mbps)
Motion control
Linear interpolation and arc interpolation
Follow-up function
High speed input and output
4~10CH 100KHz pulse outputs
4~10CH high-speed counting (max 80K for single-phase, max 50K for AB phase)
Communication function
RS232, RS485
X-NET fieldbus
